แท็คไลท์ 12ถึง30วัตต์ชีโอบี
ดาวน์โหลด
Model : KTL365A12WW/B / KTL365A20WW/B / KTL365C30WW/B
Rate Power : 12W – 30W
Luminous Flux : 1,080lm – 2,700lm
Input Voltage : AC 185 – 260 V , 50 / 60Hz
Color Temperature : CCT 3000K / 4000K / 6000K
DOWNLIGHT : SERIES KTL 365 A / B / C ADJUST
MODEL : KTL365A12WW/B / KTL365A20WW/B / KTL365C30WW/B
Specification
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Rate Power : | 12W – 30W | Beam Angle : | 10° – 50° |
| Luminous Flux : | 1,080lm – 2,700lm | Dimmable : | Non Dim /Dimmable |
| Luminous Efficiency : | 90lm/W | Driver : | Internal |
| Color Temperature : | 3000K / 4000K / 6000K | LED Chip : | COB |
| Color Rendering Index : | 80Ra | ||
| Power Factor : | >0.9 | Work Life : | 20,000hr |
| Input Voltage : | AC 185 – 260 V , 50 / 60Hz | Dimensions : | 73 x 104 mm. , 88 x 110 mm. 100 x 116 mm. |
| Color : | White / Black | Cover : | Aluminium |
| IP Rating : | IP20 |
| Power: | 12W, 20W, 30W |
|---|---|
| Colors: | Black, White |
| CCT: | 3000K, 4000K, 6000K |
| Lens: | 10° – 50° |
